Scag Skid-Mount

Make	Scag
Model	Skid-Mount
Machine Type	Truck Loader
Operating Weight	437 lbs
Airflow	3,075 CFM

Make a stand. With a beveled steel intake nozzle that makes debris pickup easy and an ambidextrous handle for better maneuverability, the Scag® Skid-Mount Truck Loader lets you stand your ground. Its welded-steel impeller with 3/8″-thick steel blades is balanced for reduced vibration and puts less stress on the engine, delivering performance for years to come.

Key Features:

Fabricated and balanced 20″, 4-blade impeller: inside the 6″-wide housing is a welded-steel impeller with 3/8″-thick steel blades. It is dynamically balanced for reduced vibration, longer life and less stress on the engine, with an effective, high-output, debris-reducing design (up to 3,075 CFM).
Optional swing-away hitch-mount: the swing-away design lets the loader move aside for dumping or removing debris from the truck, with three locking positions for versatility. Fits the TLS20-18BV model only.
10″ steel intake nozzle: a large, replaceable intake nozzle is beveled to make debris pickup easy.
Standard 4″ skid risers: four-inch skid risers with fork pockets have multiple install points to fit a wider variety of applications, or they can be removed completely.
Ambidextrous nozzle handle: a padded, large-diameter handle gives more leverage and easy maneuvering from either side.
Locking boom arm and intake nozzle: a transport lock safely secures the boom arm and hose when not in use, and a nylon bearing gives smooth movement. A transport pin locks the nozzle to the loader to help protect the hose during transport. A quick-detach hose also makes transport, storage and cleaning quick and easy.
Smart construction and easy service: a 1/4″-thick, bolt-in, replaceable wear liner extends service life, and a removable rear-housing cover gives easy access to the impeller and wear plates.

The Skid-Mount (model TLS20-18BV) moves up to 3,075 CFM and weighs 437 lbs.

Specifications:

Model: TLS20-18BV
Fuel Capacity / Tank: 1.75 gallons, engine-mounted metal tank
CFM Output: 3,075
Frame Construction: all-steel, welded
Impeller Construction: 4-blade, 3/8″-thick blades, all-steel, welded
Impeller Mounting: tapered locking hub
Impeller Diameter / Width: 20″ / 5.25″

Blower Housing Construction: removable back panel for easy impeller and wear plate access
Blower Housing Width: 6″
Blower Housing Wear Plates: standard 1/4″ steel, replaceable
Hose: 120″ length, 10″ diameter, 0.045 black thermoplastic rubber, wire helix with wearstrip
Unit Mounting: 4″ steel skid risers
Discharge Tube: clear thermoplastic, 7″ diameter
Throttle Control: commercial-grade, all-steel mechanicals, plastic debris cover
Height: 74.25″ (without skid or hitch mount attached)
Weight: 437 lbs
Accessories: LED Light Kit
Warranty: 2-Year Commercial; 2-Year Non-Commercial; 90-Day Rental
